Electronic Musician Magazine Feature
/Check out the May 2016 issue of Electronic Musician Magazine for a feature on multifunction Eurorack modules. Big thanks to Geary Yelton and the Electronic Musician team for featuring the Mordax DATA alongside a number of other excellent modules!
*FREE SHIPPING ON ALL U.S. DOMESTIC ORDERS*
DATA : The multifunction tool for Eurorack modular systems
16 HP (81.28mm width)
35mm approx. depth
Full color, 2.8” (71mm) display, with crystal clear, scratch resistant window
User upgradable firmware via included microSD card
Oscilloscope, tuner, waveform generator, clock source/div/mult, spectral display, and more
Input / Output:
4 input jacks (+/-10V range), AC or DC coupled via on-screen control
4 buffered through jacks, one for each input channel
4 output jacks (+10 to -5V range), can be CV, audio, trigger or gate signals
Power Consumption (average):
~250mA +12V
~60mA -12V
Availability: IN STOCK
Orders typically ship in 1-2 business days
Tracking number is emailed when shipped
(Check your SPAM folder if you don’t see it)
